CLW5070ZYST5 - Suizhou Liyuan Trading Co., Ltd
  • Phone:Mr zhou +86 15997916929
  • Add time:2011-07-08 11:15:17
  • Hits:1268
for the convenience of users to mention cars, our company agents to carry out car door-to-door delivery service.
the above price of vehicles, models, such as configuration and the color difference, please in order to prevail.
.
CLW5070ZYST5 Detail - Suizhou Liyuan Trading Co., Ltd
Detailed parameters
CLW5070ZYST5  Model technical parameters
Name: CLW5070ZYST5 Exterior size(mm): 6490,6240×2050×2570
Chassis: EQ1072GLJ Container size(mm): ××
Total weight :(kg) 7350 Approach angle/ Departure angle(° ) 24/12
Payload:(kg) 1805,1740 Front suspension/rear suspension(mm): 1070/2120,1070/1870
Kerb Mass:(kg) 5415(Kg) Max Speed(km/h): 90
Chassis parameters
Chassis: EQ1072GLJ Axle weight: 2940/4410
Number of axles: 2 Fuel Type: Diesel fuel
Wheelbase(mm): 3300,3800 Fronttread(mm): 1506,1590,1750
Max people in cab: 2,3 Rear tread(mm): 1530,1586,1650
Number of tires: 6 Number of spring axle: 8/9+5,8/10+7,9/10+8
Tire Type: 7.00-16,7.00R16,7.50-16,7.50R16
introduction: 1、后部翻转样式选装垃圾斗装置,并选装无后翻转机构。选装无后翻转机构时该车总长为6240mm,对应后悬为1870mm。选装垃圾斗机构时该车总长为6490mm,对应后悬为2120mm。2、防护材料:Q235碳钢,连接方式:左右侧面防护采用焊接连接,后部防护由专用装置代替豁免。3、车辆颜色、文字喷涂及局部细节可变化。4、发动机与油耗值对关系为(L/km):CY4BK251/17.8,CY4BK451/17.8,YC4FA115-50/17.8。
Engine parameters
Type Manufacturer Displacement(ml) Power(kw)
CY4BK251
CY4BK451
YC4FA115-50
东风朝阳朝柴动力有限公司
东风朝阳朝柴动力有限公司
广西玉柴机器股份有限公司
3856
3707
2982
96
86
85
other parameters
Introduction:
more Picture:
※ Need more information or pictures?please contact us and we will provide best service!。
